Absorbent Pad High Speed Sticking Machine for Plastic / Vacuum Formed / Thermoformed Box Padding

Absorbent Pad High Speed Sticking Machine for Plastic / Vacuum Formed / Thermoformed Box Padding

Absorbent Pad High Speed Sticking Machine for Plastic / Vacuum Formed / Thermoformed Box Padding


Product ID: Plastic / Vacuum Formed / Thermoformed Labeling Series 311-VP (158)

♦ In-Roll Type of Absorbent Pad.
♦ Automatic Servo Motor Control Pad Feeding System.
♦ Automatic Servo Motor Control Pad Cutting System.
♦ For Plastic Vacuum Formed / Thermoformed Box/Carton/Tray.
♦ Automatic Continuous Supplementary Feeding.
♦ No Need to Stop the Machine For Re-filling.
♦ Batched Quantity Automatic & Collecting System.

»  Specifications:

​♦ Equipped with 4-Arm Robot Box Taking System.
​♦ Equipped with 3-Jaw Cutting System.
♦ Equipped with "NORDSON" Hot-Melt Glue Applicator.
♦ Equipped with High Speed Padding System.
• Operation Speed: Approx. 2 ~ 2.2 Pieces/Sec.
• Pad Size: Max. 140 (L) * 100 (W) mm.
• Pad Roll: ø 600 (O.D.) * 76 (I.D.) mm.
• Machine Size: Approx. 8,000 (L) * 1,000 (W) * 2000 (H) mm.

»  Features:

• Japan "MITSUBISH" PLC Control System.
• Japan "YASKAWA" Servo Motor Control System.
• Interfaced 10" Colorful HMI Touch Screen Monitor.
• Padding Sensor: Japan "KEYENCE" Optoelectronic Fiber Sensor.
• Product Detect Sensor: "OMRON" Optoelectronic Sensor.

See more complete detail

♦ Product Example:
- General Food Products Box/Carton/Tray
- Fruit Box/Carton/Tray
- Sea Food Box/Carton/Tray
- Aggriculture Products Box/Carton/Tray


»  Order Information:
  • Minimum Order: Negotiable
  • Branded Product
