Glucose Test Strips Vial Compound Type Labeling Machine with Position Setting Wrap-Around & Tamper Proof Seal Labeling System

Glucose Test Strips Vial Compound Type Labeling Machine with Position Setting Wrap-Around & Tamper Proof Seal Labeling System

Glucose Test Strips Vial Compound Type Labeling Machine with Position Setting Wrap-Around & Tamper Proof Seal Labeling System


Product ID: Pharmaceutical Products Labeling Series 315-K3-PS-M6-S4 (152)

♦ Application:
For Glucose Test Strips Vial

♦ Function:
• Rolling Wrap-Around Labeling
• Automatic Alignment with Orientation & Position Setting
• Multi-Cavity Robot Transporting
• Multi-Cavity Mold-Sets with Build-in Vial Mold
• In-Mold Position Force Setting
• Tamper Proof ㄇ-Shape Seal Top Labeling

»  Specifications:

(A). Automatic Pressure Sensitive Rolling Twin-Axial Wrap-Around Labeling Section
• Vials rolling feeding
• Cylindrical substance orientation & position setting system
• Labeling position: At orientated & required set position
• Conveyor: with servo motor control
• Included X-axis labeling-head angle adjustment system
•​ Labeling height and forward/backward position adjustable

(B).  Automatic Pressure Sensitive Twin-axial -shape seal Top Labeling Section
• Multi-cavity mold-sets angle transforming system
• Transporting robot taking system
• Multi-cavity vials arraying system
•  In-mold forced position setting
•  Position setting molds
•  For tamper proof ㄇ-shape seal top labeling substances
•  Vial standing feeding
•  Cylindrical substance orientation & position setting
•  Labeling Position: At orientated & required set position
•  Included X-axial labeling-head angle adjustment system
•  Conveyor:  Servo motor control
•  Labeling System: Servo motor control



»  Features:

♦ Compound Machine (A) + (B):
• Integrated control compounded machine with robot transporting system
• One set of vial body cylindrical wrap-around labeler + one set of ㄇ-shape seal top labeler
• Compounded Operation Speed: 100 ~ 120 pcs/min
• Compounded Symmetry Labeling Precision: ± 1 mm

♦ Control System:
• Conveyor Driving: Japan "YASKAWA" servo motor control
• Labeling system: Japan "YASKAWA”servo motor control
• PLC Control System: Japan“MITSUBISH”
• Interfaced colorful touch screen monitor (HMI)
• Wrap-Around Label Sensor: German "SICK”
• Top 3-side label sensor: Japan "KEYENCE optoelectronic fiber sensor
• Product Detect Sensor: Japan "KEYENCE"




»  Order Information:
  • Minimum Order: Negotiable
  • Branded Product
