New Product Announce!


EGMFRC-68 Paper Egg Carton Automatic Feeding-Robot Labeling-Bach Collecting Labeling Machine (4-Stack-Hopper-Magazine Automatic Feeding-Labeling-Collecting)

EGMFRC-68 Paper Egg Carton Automatic Feeding-Robot Labeling-Bach Collecting Labeling Machine (4-Stack-Hopper-Magazine Automatic Feeding-Labeling-Collecting)

For Recycled Paper Pulp Series with CE Certificate is Available

Product ID: Paper Pulp Egg Carton Labeling EGMFRC-68 Multi-Axis Servo Control Series (166))

 MODEL: EGMFRC-68 (For 18 or 12-cell, For 15 or 12-Cell)
• Integrated Control Multi-Axis X-Table Robot Labeling System
• 4 Stack-Hopper-Magazine Automatic Feeding System
• Automatic Output Conveyor Discharge Type

 Designed / Operation Speed:
Approx.  25~35 / 30~35 pcs/min (10/12-cell)
Approx.  25~32 / 30~32 pcs/min (15/18-cell)

■ Application:
• Special for Recycled Paper Pulp Egg Carton/Box/Tray
• General Water Base Cold Glue Labeling
• Precut Paper Label


  TYPE: 4H10S
♦ Function & Advantages:

• Automatic Feeding-Gluing-Labeling-Collecting
• Top-Chain Conveyor with Fixed Type Mold-Sets
• Optional Inter-Changable Type Mold-Sets
• Optional Batch Collecting System
- Egg Carton/Box/Tray Feeding:
  By Vacuum Force Taking-up with Peel-Off Separating System
- 4 Sets Stack-Hopper Magazine (Fixed SideType)
- Stacked Egg Carton Integrated Control Automatic Up-Dowm
- Egg Carton/Box /Tray Feeding Automatically
- Integrated Control X-Table Robot Labeling System
- Equipped with 2-Product/1-Cycle Automatic Feeding System
- Egg Carton/Box/Tray Automatic On-Mold Transportation System
- Servo Motor Control ​Labeling & Transporting System
- Products Position-Setting Automatically
- Automatic Label Taking and Transporting System
- Automatic Gluing and Labeling Precisely
- Integrated Control with Servo Control Output Conveyor System
- Labeled Egg Cartons / Boxes / Trays:
  Automatic Change to Vertical Standing Direction
- Horizontal Stacking Output Discharge Automatically
- Labeled Products Automatic Horizonal Output Continuously

 Collecting Type to be Select:
 a). Continuous Output Discharge for Collecting.
  b). Equivalent Quantity Batched Output Discharge for Collecting.


Control System:
- Programmable Logic Control System: Japan "Mitsubishi" PLC
- Labeling System: Japan "Yaskawa" Servo Motor
- HMI: Interfaced Control Touch Screen Monitor

• Optional Hot-Melt Glue Labeling

* The brand names of products shown in the catalogue are the reference application to our manufacturing equipment only.

Order Information:
  • Minimum Order: Negotiable
  • Branded Product
