Thermoforming Deep Box / Basket Labeling Machine

Thermoforming Deep Box / Basket Labeling Machine

Thermoforming Deep Box / Basket Labeling machine

Product ID: Deep Box / Basket Labeling Machine 611E-VHMP / 622E-VHMP (150)

■ Model: 611E-VHMP / 622E-VHMP

■ Application:
• For Thermoforming Box/Basket Body Single-Side Labeling
• Example: Fruit / Vegetable Box/Basket ....

■ Main Features:
• Box to be Stacked in 3 Stack-Hopper Magazines
• Box to be loaded from Top-to-Bottom Automatically
 Box Supplementary Feeding No Need to Stop the Machine
• Servo Control Precise Labeling System
• Automatic Stacking from Bottom-to-Top for Collecting & Packing
611E-VHMP: Automatic (30-in-1) *1 Lift-Stacking
622E-VHMP: Automatic (30-in-1) *2 Lift-Stacking

Specifications:

■ Main Specification:
• Servo Control Conveyor
• Labeling Speed:
611E-VHMP: Approx. 70~80 PCS/MIN.
- 622E-VHMP: Approx. 130~150 PCS/MIN.
• 611E-VHMP / 622E-VHMP Equipped with Mold-Sets *20 / 40
• Label Size: Max. 120 (L) * 60 (H) MM
• Machine Dimension (611E-VHMP / 622E-VHMP):
   Approx. 3,700 * 1,000 / 1,700 * 1,780 MM

Features:

■   Control System:
* “MITSUBISHI” PLC Control System
* Conveyor System: “YASKAWA” Servo Motor Control System
* Labeling System: “YASKAWA” High Accuracy Servo Motor Control System
* Interfaced Colorful HMI Touch Screen Monitor
* Label Sensor: “SICK” Optoelectronic Sensor
* Product Detect: “OMRON” photoelectric sensor or equivalent brands

* The brand names of products shown in the catalogue are the reference application to our manufacturing equipment only.

Order Information:
  • Minimum Order: Negotiable
  • Branded Product
