Automatic Paper Slitting & Re-Winding Machine

Automatic Paper Slitting & Re-Winding Machine

Paper Slitting-Rewinding Machine

Product ID: Automatic Paper Slitting & Re-Winding UH-813 Series (42)

Automatic Paper Slitting & Re-Winding Machine

Model: UH-813

◊ Application
 - Jumbo Roll Paper
 - Automatic Slitting & Re-winding
 - For Paper Core Material

♦ Upper & Lower Twin-Axle Re-Winding.
♦ Manual Tension Control
♦ Auto/Manual Edge Control
♦ Parent Roll Hydraulic Loading


■ Main Specification:
- Width of Roller: 1300 mm
- Parent Roll Core: 3"~4"
- Parent Roll Diameter: ∮80 ∼ 1,300 mm
- Parent Roll Weight: Below 1.5 Tons
- Finished Roll Shaft: 75 mm (Air Shaft)
- Cutter: Upper knife & lower knife
- Slitting Width: 25~1,100 mm
- Slitting Speed: 5~180 M/Min
♦ Un-Loading:
   By Crane (Prepare by the buyer or optional procurement)


■ Main Functional Device:
• Slitting & Rewinding
• Edge Position Controller
• Edge Trimming blower
• Width Adjustment Device
• Equipped with Trimming waste material blowing pipe
• Parent Roll Stand: Hydraulic Clamp Type
• Tension Controller: Manual Air Disc Type Brake

■ Optional:
- Electric Crane
- Crane Stand
- Simple Core Cutter

Order Information:
  • Minimum Order: Negotiable
  • Branded Product
