Specifications:

￭ Specification:

A) Water Base Cold Glue/Adhesive ApplyingType:
     For Recycled Paper Pulp  Egg Box / Carton / Tray Lid

￭ Model:
• EGMA-66 Type: 2H3S (For 10/12-cell)
• EGMI-66 Type: 1H (For 10/12-cell)
• EGMRR-66 Type: 2H7S (For 10/12-cell, 2*6-cell)
• EGMRC-66 Type: 2H5S (For 10/12-cell)
• EGMRC-68 Type: 2H8S (For 15/18-cell)
• EGMFRC-66 Type: 4H7S (For 10/12-cell)
• EGMFRC-68 Type: 4H10S (For 10/12, 15/18-cell)
• EGMVAC-68 Type: VH5S (For 6,10,12,15,18-cell)
• EGMIR-68 Type: 2H6S (For 10-cell)
• EGSCLP-66 Type: 1H1S (For 10 or 12-cell, Optional 6-cell)
• EGSCLP-68 Type: 1H5S (For 10/15, 12/18-cell)
• EGDCLP-68 Type: 2H7S (For 10/15, 12/18-cell)


B) Self-Adhesive Labeling Type:
For Plastic Vacuum/Thermoforming Egg Box/Carton/Tray Lid

￭ Model:
• 311-VA-EGAA-S3 / 311-VA-EGAA-S4
- Sophisticated and Practical Model for1-Label Egg Carton/Tray Lid
• 321-VA-EGAA-S3 / 321-VA-EGAA-S4
- Sophisticated and Practical Model for 2-Label Egg Carton/Tray Lid
• 311-EGVA-S5HBC
- High Speed Model for Egg Tray Lid, Optional for Carton.
• 322-EGVA-S7HBC
- High Speed Model for Egg Tray Lid, Optional for Carton.
• 310-VS-EG-S1
- Economical Type, Single-Label for Egg Carton
• 320-VS-EG-S2 (For Egg Carton)
- Economical Type, Double-Label for Egg Carton
• 310-VS-EGMA (For Egg Carton)
- Stack-Hopper Type, Single-Label for Egg Carton

Features:

￭ Features:

(A) Water Base Cold Glue/Adhesive Applying Models:
  -    For Recycled Paper Pulp  Egg Box / Carton / Tray Lid

• EGSCLP-68: 1H5S (10/15, 12/18-cell)
• EGDCLP-68 : 2H7S (10/15, 12/18-cell)
- Can be Added Additional Accessories for Multi-Application
- Integrated Control X-Table Robot System
  with 1/2 Sets  Stack-Hopper Automatic Feeding System
- Fixed /Adjustable/Interchangeable Type Product Feeding
  (Depend on Product)
- Multi-Axis Servo Control Twin-Labeling System
- Automatic Direct 1 or 2-stage Separating-Taking-Feeding
- Servo Control Conveyor Transporting System without Mold-Sets
- Automatic Lift-Stacking Discharge for Collecting
- Batched Collecting System
- Design/Operation: Approx. 27~32/25~30 pcs/min (EGSCLP)
- Design/Operation: Approx. 60~70/60~65 pcs/min (EGDCLP)

• EGMIR-68 Type: 2H6S (10-cell)
- Integrated Control X-Table Robot System
  with 2 Sets  Stack-Hopper Fixed Type Automatic Feeding System
- Multi-Axis Servo Control Twin-Labeling System
- Automatic Direct Separating-Taking-Feeding
- Indexing Disc Transporting System with Mold-Sets
- Automatic Lift-Stacking Discharge for Collecting
- Batched Collecting System
- Design / Operation Speed: Approx. 60~70 / 55~60 pcs/min

• EGMFRC-66 Type: 4H7S (10/12-cell)
• EGMFRC-68 Type: 4H10S (10/12, 15/18-cell)
- Integrated Control X-Table Robot System
  with 4 Sets  Stack-Hopper Fixed Type Automatic Feeding System
- Automatic Vacuum Taking-Separating-Feeding
- Servo Control Transporting Conveyor with Mold-Sets
- Automatic Output Conveyor System for Collecting
- EGMFRC-66 Design / Operation Speed:
  Approx. 25~35 / 32~35 pcs/min (10 /12-cell)
- EGMFRC-68 Design / Operation Speed:
  Approx. 25~35 / 32~35 pcs/min (10 /12-cell)
  Approx. 25~32 / 30~32 pcs/min (15 /18-cell)

• EGMRR-66 Type: 2H7S (10/12-cell, 2*6-cell)
- Integrated Control Robot System with Fixed Type Mold-Sets
- Feeding & Collecting Each 2 Sets Hopper
- Automatic Feeding & Collecting by X-Table Type
- Servo Control Conveyor with Mold-Sets
- Design / Operation Speed (10,12-cell):
  Approx. 20~30 / 25~28 pcs/min (10,12-cell)
  Approx. 20~28 / 22~25 pcs/min (2*6-cell)

• EGMI-66 Type: 1H (10/12-cell)
- Indexing Disc Transporting System
- Designed / Reference Speed: 30 / 16~25 pcs/min

• EGMA-66 Type: 2H3S (10/12-cell)
- Automatic labeling
- Automatic feeding & collecting
- Designed / Operation Speed: Approx. 15~25 / 16~22 pcs/min

• EGMRC-66 Type: 2H5S (10/12-cell)
• EGMRC-68 Type: 2H8S (15/18-cell)
- Integrated Control X-Table Robot System
  with 2 Sets  Stack-Hopper Fixed Type Automatic Feeding System
- Servo Control Transporting Conveyor with Mold-Sets
- Automatic Vacuum Taking-Separating-Feeding
- Automatic Output Conveyor Systemfor Collecting
- EGMRC-66Series Design / Operation Speed:
  Approx. 20~30 / 24~28 pcs/min
- EGMRC-68 Series Design / Operation Speed:
  Approx. 20~28 / 22~25 pcs/min

• EGMVAC-68 Type: VH5S (6, 10, 12, 15, 18-cell)
- Multi-Application Type
- Integrated Control X-Table Robot System
- Horizontal Stacking Type Automatic Feeding System
- Automatic Vacuum Taking-Separating-Feeding
- Servo Control Transporting Conveyor without Mold-Sets
- Automatic Output Conveyor System for Collecting
- Design / Operation Speed:
  Approx. 22~35 / 22~28 pcs/min depend on product quality & spec.

(B) Self-Adhesive Labeling Models:
 -    Plastic  Vacuum/Thermoforming Egg Box/Carton/Tray Lid

• 311-VA-EGAA-S3 (Single-Labeling, Continuous Collecting)
• 321-VA-EGAA-S4 (Double-Labeling,Continuous Collecting)
• 311-VA-EGAA-S4 (Single-Labeling, Batch Collecting)
• 321-VA-EGAA-S5 (Double-Labeling,Batch Collecting)

- Automatic Feeding & Collecting
- Continuous Supplementary Feeding System
- Continuous Supplementary Feeding System
- Design /Operation Speed: Approx. 45~50 / 35~42 pcs/min

• 310-VS-EGMA
- Automatic Feeding & Collecting
- Egg Carton Stack-Hopper Storage Feeding Type
- Equipped with Mold-Sets
- Designed / Operation Speed: Approx. 15~30 / 20~25 pcs/min

• 310-VS-EG-S1 / 320-VS-EG-S2
- Economic Single / Double Labeling System
- Feeding & Collecting by manual
- Equipped with Egg box adapted transporting conveyor
- Designed / Operation Speed: Approx. 35~45 / 30~40 pcs/min


C). Label Insert Labeling Type:
 -   For Plastic Thermoforming Egg Box / Carton / Tray

• 110-VA-EGAA-S4
- Automatic Label Inserting System
- Automatic Feeding & Collecting
- Continuous Supplementary Feeding System
- Automatic Collecting System
​- Equipped with Hot-Melt Glue Applicator
- Design /Operation Speed: Approx. 25~35 / 20~30 pcs/min.

Order Information:

• Minimum Order: Negotiable
• Branded Product
