Specifications:

￭ Main Specification:
1. Parts Arranging and Feeding (Lower Cap) – 500 Ø * 1
a) Un-scrambler
b) Un-scrambler frame
c) Overflow control system
d) Components delivery mechanism (Horizontal delivery system)

2. Un-scrambler Storage Tank (Lower Cap) * 1
-   500 * 500 mm
-   With overflow control system

3. Parts Arranging and Feeding (Upper Cap) – 500 Ø * 1
a) Un-scrambler
b) Un-scrambler frame
c) Overflow control system
d) Components delivery mechanism (Horizontal delivery system)

4. Un-scrambler Storage Tank (Upper Cap) * 1
-   500 * 500 mm
-   With overflow control system

5. Machine Main Structure (1-Mold, 2-Cavity) * 1
a) Main machine structure
b) Indexing Table Positioning System
-   Ø 600mm * 850 H disc
-   8 stations
-   Brake Clutch Motor
-   Motor drive positioning
c) 8-station mold-sets for assembly molds
d) Aluminum Alloy Engraved mold x 8 sets (1-Mold, 2-Cavity)

6. Assembly System
a) Automatic cap separating system (upper/lower cap) * 2
b) Automatic cap suction take-feeding system (upper/lower cap) *2
c) Prevent rotation clamping system (lower cap) * 2
d) Automatic cap twist assembly system (upper cap)* 2
e) AC motor control 25 W “OGURA” torque control system * 2
f)  Automatic transfer delivery discharging device * 1
g)  Sensor control system
h)  Caps detect system

Features:

Order Information:

• Minimum Order: Negotiable
• Branded Product
