Plastic / Vacuum Formed / Thermoformed Tray / Carton / Box High Speed Labeling Machine with Four Labeling-Head

Plastic / Vacuum Formed / Thermoformed Tray / Carton / Box High Speed Labeling Machine with Four Labeling-Head

Product ID: Plastic / Vacuum Formed / Thermoformed Labeling Series 342-HVC (154)

■   High Speed  Self-Adhesive Labeling Machine for:
      Plastic / Vacuum Formed / Thermoformed Box / Carton / Tray


• Labeling Speed: Approx. 200 ~ 220 Pieces/Min
• For Self-Adhesive Type Of Label
• Servo Motor Control Top Labeling System
• Equipped With 4 Individual Angle Adjustable Labeling-Head
• Automatic 2-Lane Continuously Supplementary Feeding System
• High Speed Taken-Off By Robot Arm
• No Need To Stop The Machine For Re-Filling
• High Speed Continuously Automatic Collecting System
• Automatic Batched Equivalent Quantities Collecting System



»  Specifications:

* Machine Body & Frame: Aluminum Alloy With Anodizing Treatment and Stainless Steel
* Collecting Accumulation & Delivery System
* Chain Type Forming Box Delivery System
* Labeled Forming Boxes Working Table
* Conveyor: 5,000 Mm (L) X 800 Mm (W) X 850 Mm (H)
* Labeling Height And Forward/Backward Position Adjustable
* Labeling Product Size: 120 ~ 400 (L) X 120 ~ 300 (W) mm
* Label Size: Max. 200 (L) X 120  (H)  mm Included Base Paper
* Label Roll: ∮300 O.D. & ∮76  I.D. mm
* Machine Dimension: 9,400 (L) X 1,200  (W) X 1800  (H) mm
* Compressed Air Needed:
     6 KGS/CM2 With Reserve Tank And Dehumidifier

»  Features:

■   Control System:
* Japan “MITSUBISHI” PLC Control System
* Conveyor System: Japan“YASKAWA”Servo Motor Control System
* Labeling System: Japan“YASKAWA”High Accuracy Servo Motor Control
* Interfaced 10” Colorful HMI Touch Screen Monitor
* Label Sensor: “SICK” Optoelectronic Sensor
* Product Detect: Japan “OMRON” optoelectronic sensor special for transparent product

■  Advantage:
* For 2-Lane Vacuum Forming Type of Box/Tray
* Forming Boxes Nonstop Continuous In-Feed And To Be Separated Automatically
* High Speed Feeding And Collecting
* High Precision Labeling
* Intermittent Collecting For Batched Labeled Boxes Automatically
* Labeling Accuracy: ± 2.0 MM
    (Depend On The Design Of Vacuum Forming Box).
* Visible Safety Guard Door With # 440 Aluminum Frame
* Economic And High Efficiency With Very Less Manpower* With Emergency Stop Device

* The brand names of products shown in the catalogue are the reference application to our
   manufacturing equipment only.







»  Order Information:
  • Minimum Order: Negotiable
  • Branded Product
