5-Gallon Drinking Water Bottle Cap Automatic Cap-Liner-Plug Assembly & Heat Seal Labeling Machine

5-Gallon Drinking Water Bottle Cap Automatic Cap-Liner-Plug Assembly & Heat Seal Labeling Machine

5-Gallon Water Bottle Cap Automatic Cap-Liner-Plug Assembly & Heat Seal Labeling Machine


Product ID: Assembly-Lining-Heat Seal Labeling for 5-Gallon Drinking Water Bottle Cap (37)

♦ Application:

(A) Model: UAF-842-CPLS Series

■  5 Gallon Bottle Cap-Liner-Plug Assembly & Seal-Labeling

• Cap / Closure to be Inserted with Liner and Inner Plug Assembly
• Aluminum-Liner or Paper-Liner or EPE Sponge-Liner
• Liner with Tab or without Tab to Be Selected
• Heat Seal Type Labeling

(B) Model: UAF-842-CS Series

■ 5 Gallon Bottle Cap Seal-Labeling

• Cap / Closure Heat Seal Type Labeling

»  Specifications:

■ Models:
Model UAF-842 Series capacity: 96 ~ 100 PCS/MIN
Model UAF-841 Series capacity: 40 ~  60 PCS/MIN


Equipped with Special Designed System:
  -
Substance Components Supply Detect System

♦ Optional :

(1). Assembled Products Viewing-Inspection Output Conveyor.
   (2). Output Conveyor with Detect System.
   (3). Process Detect System:
       - Process Components Shortage Detect System
       - Process Components Abnormal Assembled Detect System
       - Abnormal Products Reject System

»  Features:

Functions:
• Caps / Liners / Plugs Feeding Automatically
• Products Position-Setting Automatically with Mold-Sets System
• Liners Feeding Automatically by Stack-Hopper Magazine System
• Liners Automatic Separating and Take-Off System
• PLC Programmable Logic Control System
• Inter-faced Colorful Touch Screen Monitor Control System (HMI)
• Liner Stack-Hopper Magazine (2 types to be optional):
   (a). Allowed Continuous Re-Fill Liners without Stopping Machine
   (b). Stop Machine for Re-filling
• Caps Assembly Automatically
• Cap & Plastic Film Sealing Automatically
• Assembled Caps Automatic Take-Off & Discharge System

♦ Types:
  Type A): Cap-Liner-Inner Plug Assembly
  Type B): Cap-Liner Assembly without Inner Cap
  Type C): Cap-Inner Plug Assembly without Liner


* The brand names of products shown in the catalogue are the reference application to our manufacturing equipment only.



»  Order Information:
  • Minimum Order: Negotiable
  • Branded Product
